IQ8 MCP addressable manual call point with membrane for Atex IP 66 zone: the ideal fire solution.
The IQ8 MCP addressable manual call point is equipped with a status indicator, a membrane, a transparent protective cover and a mounting base. It is an ESSER fire device designed to be installed in premises classified Atex zone 1 (category II 2G) with an intrinsic safety barrier 804744.
Thanks to its high degree of protection ( IP 66 ), it is suitable for installation in damp rooms. In this case, it must be fitted with an M20 cable gland suitable for an Atex environment.
Treat yourself to the IQ8 MCP addressable manual call point with membrane for Atex IP 66 zone - 804963.EX.F0 at the best price on the market and discover many other products in the Esser category on Glotelho.cm, the leader in online sales in Cameroon.
Specifications of the IQ8 MCP 804963.EX.F0 addressable manual call point.
- Brand : ESSER
- Product Type : Manual Triggers
- Category : Network and Telecom
- Model : 804963.EX.F0
- Max. Input Voltage (Ui) 21 Vdc
- Max. Input current (Ii) 252 mA
- Ambient temperature (Ta) : -20°C ... 70°C
- Category II 2G : (with Ex barrier ref. 764744 / 804744)
- Explosion protection Ex ib IIC T4 Gb
- Quiescent current @ : 19 V DC Approx. 0μA
- Alarm current @ : 9V DC 9mA
- Storage temperature : -30°C ... 75°C
- Relative humidity: < 95%
- Index protection : IP44, IP55 with cable gland
- Plastic housing : PC-ASA
- Colour : red like RAL 3020
- Approx weight : 250g
- Certification according to EN 54-11 : 2001 + A1:2005, Type B
- High protection index : IP 66
- Atex installation in zone 1 (group IIC T4) with intrinsic safety barrier 804744
- Supplied with triple function key : (Test, opening, resetting)
- Removable terminal block
- Transparent protective cover
